A C64 Game - Step 33

More refinement in this step. This step marks a design change in gameplay. Before the game was planned to be more survival based, with enemies that hunt you about. Beginning with this step the game play gets more Bubble Bobble like.


For one the zombies are changed. Their animation is enhanced and they learned to jump. Also, mummies now attack if they see the player (ie. look in his direction). Plus the left/right moving bat is changed to move diagonally.



Until now the jump variables were only available to the player. Now we rename the PLAYER_JUMP_xxx variables to SPRITE_JUMP_xxx and allow a range of all 8 sprites.

The diagonal moving bat is added. This is quite simple, we add a second direction variable (SPRITE_DIRECTION_Y) for the vertical direction. Copy over the left/right moving code and adjust it to vertical movement. Done!

;------------------------------------------------------------
;simply move diagonal
;------------------------------------------------------------

!zone BehaviourBatDiagonal
BehaviourBatDiagonal
          lda DELAYED_GENERIC_COUNTER
          and #$3
          bne .NoAnimUpdate

          inc SPRITE_ANIM_POS,x
          lda SPRITE_ANIM_POS,x
          and #$3
          sta SPRITE_ANIM_POS,x
          tay
          lda BAT_ANIMATION,y
          sta SPRITE_POINTER_BASE,x

.NoAnimUpdate
          lda SPRITE_DIRECTION,x
          beq .MoveRight

          ;move left
          jsr ObjectMoveLeftBlocking
          beq .ToggleDirection
          jmp .MoveY

.MoveRight
          jsr ObjectMoveRightBlocking
          beq .ToggleDirection
          jmp .MoveY

.ToggleDirection
          lda SPRITE_DIRECTION,x
          eor #1
          sta SPRITE_DIRECTION,x

.MoveY
          lda SPRITE_DIRECTION_Y,x
          beq .MoveDown

          ;move up
          jsr ObjectMoveUpBlocking
          beq .ToggleDirectionY
          rts

.MoveDown
          jsr ObjectMoveDownBlocking
          beq .ToggleDirectionY
          rts

.ToggleDirectionY
          lda SPRITE_DIRECTION_Y,x
          eor #1
          sta SPRITE_DIRECTION_Y,x
          rts

For the mummy to react to the player we add this snippet in front of its behaviour code. Detecting the player is done the naive way. The player has to be at the same height (the same char y pos), and the mummy has to look in its direction.

If all these conditions are matched the mummy assumes its attack stance and hurries towards the player.

          lda SPRITE_CHAR_POS_Y,x
          cmp SPRITE_CHAR_POS_Y
          bne .NoPlayerInSight

          ;player on same height
          ;looking at the player?
          lda SPRITE_DIRECTION,x
          beq .LookingRight

          lda SPRITE_CHAR_POS_X,x
          cmp SPRITE_CHAR_POS_X
          bpl .LookingAtPlayer
          jmp .NoPlayerInSight

.LookingRight
          lda SPRITE_CHAR_POS_X,x
          cmp SPRITE_CHAR_POS_X
          bmi .LookingAtPlayer
          jmp .NoPlayerInSight

.LookingAtPlayer
          lda #SPRITE_MUMMY_ATTACK_R
          clc
          adc SPRITE_DIRECTION,x
          sta SPRITE_POINTER_BASE,x
          lda SPRITE_DIRECTION,x
          beq .AttackRight

          ;attack to left
          jsr ObjectMoveLeftBlocking
          jsr ObjectMoveLeftBlocking
          beq .ToggleDirection
          rts

.AttackRight
          ;attack to left
          jsr ObjectMoveRightBlocking
          jsr ObjectMoveRightBlocking
          beq .ToggleDirection
          rts

.NoPlayerInSight
          ... old behaviour

Allowing the zombie to jump is pretty easy as well. We already have jumping code for the player. In this step we however just copy the code over. The actual jump code starts at the .jump label.

Increase the jump cointer, fetch the Y movement from a jump table and move the sprite upwards. Once the zombie reaches the end of the table (the peak of the jump) we simply let gravity set in.

!zone BehaviourZombie
BehaviourZombie
          lda SPRITE_JUMP_POS,x
          bne .IsJumping
          jsr ObjectMoveDownBlocking
          bne .Falling

.IsJumping
          lda DELAYED_GENERIC_COUNTER
          and #$3
          beq .MovementUpdate
          rts

.Falling
          rts

.MovementUpdate
          lda SPRITE_JUMP_POS,x
          bne .UpdateJump
          lda SPRITE_STATE,x
          bne .OtherStates
          jsr GenerateRandomNumber
          cmp #17
          beq .Jump
          jmp .NormalWalk

.OtherStates
          ;collapsing?
          cmp #128
          beq .Collapsing1
          cmp #129
          beq .Collapsing2
          cmp #131
          bne .NotWakeUp1
          jmp .WakeUp1

.NotWakeUp1
          cmp #132
          bne .NotWakeUp2
          jmp .WakeUp2

.NotWakeUp2
          cmp #130
          bne .NotHidden
          jmp .Hidden

.NotHidden
          rts

.Jump
          ;start jump
          lda #SPRITE_ZOMBIE_JUMP_R
          clc
          adc SPRITE_DIRECTION,x
          sta SPRITE_POINTER_BASE,x

.UpdateJump
          inc SPRITE_JUMP_POS,x
          lda SPRITE_JUMP_POS,x
          cmp #JUMP_TABLE_SIZE
          bne .JumpOn

          ;jump done
          lda #0
          sta SPRITE_JUMP_POS,x
          rts

.JumpOn
          ldy SPRITE_JUMP_POS,x
          lda JUMP_TABLE,y
          bne .KeepJumping
          rts

.KeepJumping
          sta PARAM5

.JumpContinue
          jsr ObjectMoveUpBlocking
          beq .JumpBlocked
          dec PARAM5
          bne .JumpContinue
          rts

.JumpBlocked
          lda #0
          sta SPRITE_JUMP_POS,x
          rts

          ... common zombie behaviour

step33.zip
